95% of files need to be re-exported for a simple mistake

95% of files need to be re-exported for a simple mistake

Play Video
Don’t miss another deadline.

Try cineX Suite.

Don’t miss another deadline. Try cineX Suite.

Start your free trial

Start your free trial

cineX Suite free trial gives you access to cineXtools, cineXmeta and cineXplugins. All free trial versions can be used on any supported file types up to 5 minutes long. If you’d like a full length free trial, please contact sales[at]cinedeck.com

Who is using cineXsuite?

Who’s using cineX suite?

“We can just fix what we need to fix without re-sending the file through QC.”

640px-Technicolor_logo.svg

“Historically, if there was an issue, we would restart the whole process. Now, we just drop in the change.”

225px-ITN_logo.svg

“We can offer our clients a better service because we can turn around last minute changes nearly instantly”

envy-1

Features

Features

  • Resolution Independent. This means HD, 4K and even 8K are all supported
  • Multiclip Insert: Insert multiple clips at once
  • Add, remove and reconfigure audio tracks
  • Create an AS11 file delivery
  • Edit, add, delete 608 and 708 captions
  • Change from drop to non-drop timecode

For MXF Files

Wrapper:

  • Start timecode (timecode restripe)
  • Timecode Drop/nondrop value (timecode restripe)
  • Frame rate
  • Closed Captions present (allows delete of captions track if user sets to no)
  • Law Rating Type (can add to file without atom present)
  • Law Rating value(s)
  • AFD (4×3, 14:9, 16:9 etc)

Video Track:

  • Track ID (change track order, eg move video track from last to first)
  • Scan type (Progressive or Interlaced)
  • Scan order (interlaced only)
  • Scan store method (interlaced only)
  • Display aspect ratio (PAL, NTSC, DV, DV 16×9, HD etc)
  • Color information:
  • – Color Primaries
  • – Transfer Characteristics
  • – Matrix Coefficients
  • Range (SMPTE, CGR)

Audio Tracks:

  • Track ID (reorder audio tracks)
  • Track Title
  • Channel Label
  • Channel Language

Wrapper:
Start timecode (timecode restripe)
Timecode Drop/nondrop value (timecode restripe)
Frame rate
Reel ID (text string)
Closed Captions present (allows delete of captions track if user sets to no)
Law Rating Type (can add to file without atom present)
Law Rating value(s)

Video Track:
Track ID (change track order, eg move video track from last to first)
Scan type (Progressive or Interlaced)
Scan order (interlaced only)
Scan store method (interlaced only)
CLAP atom present (allows delete of CLAP atom if user sets to no, eg for UHD)
CLAP atom preset (SD, HD, DV etc)
Pixel aspect ratio (PAL, NTSC, DV, DV 16×9, HD etc)
COLOR atom
– Color Primaries
– Transfer Characteristics
– Matrix Coefficients

HDR Information:
– HDR-format
– Mastering Display Color Primaries
– Mastering Display Luminance
– Maximum Content Level
– Maximum Frame Average Light Level
Range (SMPTE, CGR)
Gamma (invalid if COLOR atom present)

Audio Tracks:
Track ID (reorder audio tracks)
Track Title
Channel Label
Channel Language

Pricing

Pricing

Everything cineXtools makes for one flat fee

cineX Suite includes all options and codecs for cineXtools including the captions editor and AS11 editor, all codecs for cineXplugins and all options for cineXmeta.

Note: In order to activate your license and use cineX products with the Cinedeck license, you will need to be in Admin mode. If you are not able to be in Admin mode for licensing and usage, please purchase iLok Licensing.

cineXsuite

per year

24 hours of cineX Suite (1 day)

cineXplugins

choose the codec below

cineXmeta

all wrappers / per year

If you’d like to purchase more than one license at time, please email sales[at]cinedeck.com

We’ve created our own licensing mechanism to make trial licenses simpler, but found that many customers prefer not to use iLok to keep their overall licensing simple. While there are limitations to the new licensing mechanism, there is a huge benefit to simplicity of use.

Does the new licensing support floating licenses?
No, floating licenses are not supported
Can the new license be moved from system to system?
No, the machine key that creates the license is unique so the license stays with the system
running the license
What happens if the computer dies and the license is not available?
Cinedeck will reissue a license on a case by case basis, not to exceed one re-issue per 1yr
subscription
Can the new license be used on a VM?
This is similar to the floating license question and the answer is no. Every time a VM is spun up, the machine ID would change. So, a new license would need to be issued.
How does the licensing mechanism work?
You can review how to activate your license here: cineX Suite Knowledge Base.

Don't waste another second

Don’t waste another second

CineX suite reduces delivery cycles by letting you update just the change without re-export, helping you to streamline your file mastering process. cineX Suite is comprised of three components, cineXtools, cineXplugins and cineXmeta, that all work together to supercharge your file deliveries.

versus

Technical Specifications

Technical Specifications

  • ProRes – all qualities
  • DNxHD / HR – all qualities
  • XAVC, class 300 and 400
  • AVC-I
  • XDCAM
  • JPEG2000
  • H.264* (needs to be cineX created)

SD, HD, 2K, UHD, 4K, 8K and beyond.

cinextools is resolutions independent. If you’re using a raster independent codec like ProRes, it can be any non-standard resolution.

MOV, OP1A MXF, OPATOM MXF, MP4

cineXtools support for Colorspace and bit depth depend entirely on the codec, but generally cineXtools supports YUV 8, YUV 10, RGB10 and RGB12.

On a related, but separate note, cineXtool supports HDR files, like ProRes XQ for insert, too. Like the insert support for codecs, cineXtools does colorspace conversions when inserting from source to target. So, a 10-frame RGB12 DPX sequence can be inserted to your YUV10 ProRes HQ file. For obvious reasons, we wouldn’t recommend you go from YUV8 to RGB12.

For PC, Windows 10 and higher

For Mac, MacOS 10.15 (Catalina) and greater

There are no minimum hardware requirements for cineXtools. However the faster / better your hardware, the faster your inserts and rewrap processes.

One important factor in the speed of cineXtools is where the file is located and network bandwidth. If your file is located on a busy network then the speed of insert and rewrap, particularly, may be slow. It’s always best to run cineXtools as “close” to your target file as possible.

cineXtools provides authorization codes for use on desktop environments. For more information, check out our user guides pages here.

FAQ and Getting Started

FAQ and Getting Started

The latest software is located on our User Resources Page here

You can also find training guides, videos and information on how to activate your license.

If you work in the Mac space, your Mac computer needs to be macOS 10.15 (Catalina) and newer

If you are in the Windows world, make sure your device is running Windows 7 x64 (64-bit) Service Pack 1 or newer.

A more powerful system will perform better when running CineXtools. But, because most real processing is for small bits of video and audio, the biggest factor is disk I/O for read and write.

You’ll see the best performance when you work on SSDs, particularly for the target drive. A fast local RAID or fast network storage on an 8 Gigabit or faster connection will help, too. Avoid working on devices such as a USB2 single platter spinning hard drive.

If you have any questions, please get in touch.

ProRes is a very common codec used to encode video file. Each frame gets compressed using a different amount of data and results in every frame being a slightly different size.

To do video inserts into a target file, each frame needs to be big enough for a maximum potential data overwrite.

The rewrap is a padding process and has no effect on the video essence and is very fast, much like a file copy.

Go here to learn more about the rewrap process.

Yes, cineXtools is available for both Mac and PC.

Both versions support the same features. Generally, you can use any Mac running OS X 10.9 (AKA Mavericks) or newer. You can also use any Windows system running Windows 7 x64 (64-bit) Service Pack 1 or newer.

No, there are no functional differences between the Mac and PC versions. Both versions support ProRes, as well.

ProRes Export Plugins are software components that make delivering ProRes files simpler. We partnered with various non-linear video editing software providers to develop them.

As a result, you can export an ‘insertable’ Padded ProRes file straight from the NLE of your choice. Forget about ProRes master file preparation delays.  You can apply audio, video, and closed caption insert-edits to your files immediately.

Learn more about and request the free plugins here.

iLok License Manager must be configured for automatic discovery of network servers OR a config file needs to be generated by the iLok manager running the license server, and that config file copied to the local machine. In order for automatic discovery to take place, the Bonjour service needs to be running and set to automatic startup. Check that you have the server set for automatic discovery on the systems that won’t launch.


The dialog is accessed via the file::preferences menu in the iLok manager.

Running cineXtools under virtual machines (VMs) is neither tested extensively nor officially supported because of known issues with features that rely on the graphics processor and other hardware in VM environments.

Use of cineXtools on a virtual machine (VM) is “at your own risk” and support will not be able to help with any issues.

Contact Us

Contact Us
